Spring Strut and Spring Strut Mounting Front for 2009 Mercedes-Benz SLK300
No.
Part # / Description / Price
Price
10
MSRP $270.00
$189.54
10
MSRP $314.00
$219.96
20
MSRP $30.00
$22.86
30
Helical Spring
Mercedes-Benz
Mercedes-Benz Notes: IN ORDER TO DETERMINE THE FRONT SPRINGS THE POINTS IN THE FOLLOWING TABLE FOR THE RESPECTIVE MODEL SERIES AND THE
SPECIAL VERSION AS INSTALLED ARE TO BE ADDED UP
==============================================================================================================================
MODEL DESIGN. POINT COUNT CODE SPECIALEQUIPMENT POINT COUNT
171.442 170 275 MEMORY 1
171.454 186 423 AUTOM. 5-SPEED TRANS. 4
171.445 170 424 SEQUENTRONIC 1
481 UNDERBODY PROTECTION 2
171.454 186 523-530 RADIO/COMAND/NAVIGATION 1
580/581 AUTOMATIC AIR CONDITIONING 4
171.456 190 600 HEADLAMP CLEANING SYSTEM 1
614/618 BI-XENON LIGHT 1
171.458 190 673 BATTERY WITH HIGHER CAPACITY 2
810 SOUND SYSTEM 1
171.473 203 873 SEAT HEATER 1
875 HEATED HEADLAMP CLEANING SYSTEM 1
==============================================================================================================================
SUM OF POINTS... TABLE, FRONT.. SPR. - SERIES
442/445 454/456/458/473
-173 -180 A171 321 03 04
174-183 181-185 A171 321 04 04
184-192 186-193 A171 321 05 04
193-250 194-250 A171 321 09 04
================================================================================================-=============================
TABLE, FRONT.. SPRING - 486 (SPORTS SUS.)
442/445 454/456/458/473
-179 -180 A171 321 06 04
180-184 181-185 A171 321 07 04
185-193 186-193 A171 321 08 04
194-250 194-250 A171 321 10 04
=============================================================================================================================
Description: Color marking: 1 x white/2 x blue.
MSRP $92.00
$67.10
MSRP $92.00
$67.10
30
Front Axle Spring Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
IN ORDER TO DETERMINE THE FRONT SPRINGS THE POINTS IN THE FOLLOWING TABLE FOR THE RESPECTIVE MODEL SERIES AND THE SPECIAL VERSION AS INSTALLED ARE TO BE ADDED UP ============================================================================================================================== MODEL DESIGN. POINT COUNT CODE SPECIALEQUIPMENT POINT COUNT 171.442 170 275 MEMORY 1 171.454 186 423 AUTOM. 5-SPEED TRANS. 4 171.445 170 424 SEQUENTRONIC 1 481 UNDERBODY PROTECTION 2 171.454 186 523-530 RADIO/COMAND/NAVIGATION 1 580/581 AUTOMATIC AIR CONDITIONING 4 171.456 190 600 HEADLAMP CLEANING SYSTEM 1 614/618 BI-XENON LIGHT 1 171.458 190 673 BATTERY WITH HIGHER CAPACITY 2 810 SOUND SYSTEM 1 171.473 203 873 SEAT HEATER 1 875 HEATED HEADLAMP CLEANING SYSTEM 1 ============================================================================================================================== SUM OF POINTS... TABLE, FRONT.. SPR. - SERIES 442/445 454/456/458/473 -173 -180 A171 321 03 04 174-183 181-185 A171 321 04 04 184-192 186-193 A171 321 05 04 193-250 194-250 A171 321 09 04 ================================================================================================-============================= TABLE, FRONT.. SPRING - 486 (SPORTS SUS.) 442/445 454/456/458/473 -179 -180 A171 321 06 04 180-184 181-185 A171 321 07 04 185-193 186-193 A171 321 08 04 194-250 194-250 A171 321 10 04 =============================================================================================================================
IN ORDER TO DETERMINE THE FRONT SPRINGS THE POINTS IN THE FOLLOWING TABLE FOR THE RESPECTIVE MODEL SERIES AND THE SPECIAL VERSION AS INSTALLED ARE TO BE ADDED UP ============================================================================================================================== MODEL DESIGN. POINT COUNT CODE SPECIALEQUIPMENT POINT COUNT 171.442 170 275 MEMORY 1 171.454 186 423 AUTOM. 5-SPEED TRANS. 4 171.445 170 424 SEQUENTRONIC 1 481 UNDERBODY PROTECTION 2 171.454 186 523-530 RADIO/COMAND/NAVIGATION 1 580/581 AUTOMATIC AIR CONDITIONING 4 171.456 190 600 HEADLAMP CLEANING SYSTEM 1 614/618 BI-XENON LIGHT 1 171.458 190 673 BATTERY WITH HIGHER CAPACITY 2 810 SOUND SYSTEM 1 171.473 203 873 SEAT HEATER 1 875 HEATED HEADLAMP CLEANING SYSTEM 1 ============================================================================================================================== SUM OF POINTS... TABLE, FRONT.. SPR. - SERIES 442/445 454/456/458/473 -173 -180 A171 321 03 04 174-183 181-185 A171 321 04 04 184-192 186-193 A171 321 05 04 193-250 194-250 A171 321 09 04 ================================================================================================-============================= TABLE, FRONT.. SPRING - 486 (SPORTS SUS.) 442/445 454/456/458/473 -179 -180 A171 321 06 04 180-184 181-185 A171 321 07 04 185-193 186-193 A171 321 08 04 194-250 194-250 A171 321 10 04 =============================================================================================================================
Description: Color marking: 1 x white/1 x orange.
30
Helical Spring Mercedes-Benz
Mercedes-Benz Notes: IN ORDER TO DETERMINE THE FRONT SPRINGS THE POINTS IN THE FOLLOWING TABLE FOR THE RESPECTIVE MODEL SERIES AND THE
SPECIAL VERSION AS INSTALLED ARE TO BE ADDED UP
==============================================================================================================================
MODEL DESIGN. POINT COUNT CODE SPECIALEQUIPMENT POINT COUNT
171.442 170 275 MEMORY 1
171.454 186 423 AUTOM. 5-SPEED TRANS. 4
171.445 170 424 SEQUENTRONIC 1
481 UNDERBODY PROTECTION 2
171.454 186 523-530 RADIO/COMAND/NAVIGATION 1
580/581 AUTOMATIC AIR CONDITIONING 4
171.456 190 600 HEADLAMP CLEANING SYSTEM 1
614/618 BI-XENON LIGHT 1
171.458 190 673 BATTERY WITH HIGHER CAPACITY 2
810 SOUND SYSTEM 1
171.473 203 873 SEAT HEATER 1
875 HEATED HEADLAMP CLEANING SYSTEM 1
==============================================================================================================================
SUM OF POINTS... TABLE, FRONT.. SPR. - SERIES
442/445 454/456/458/473
-173 -180 A171 321 03 04
174-183 181-185 A171 321 04 04
184-192 186-193 A171 321 05 04
193-250 194-250 A171 321 09 04
================================================================================================-=============================
TABLE, FRONT.. SPRING - 486 (SPORTS SUS.)
442/445 454/456/458/473
-179 -180 A171 321 06 04
180-184 181-185 A171 321 07 04
185-193 186-193 A171 321 08 04
194-250 194-250 A171 321 10 04
=============================================================================================================================
Description: Color marking: 1 x yellowith 1 x red.
30
Helical Spring Mercedes-Benz
Mercedes-Benz Notes: IN ORDER TO DETERMINE THE FRONT SPRINGS THE POINTS IN THE FOLLOWING TABLE FOR THE RESPECTIVE MODEL SERIES AND THE
SPECIAL VERSION AS INSTALLED ARE TO BE ADDED UP
==============================================================================================================================
MODEL DESIGN. POINT COUNT CODE SPECIALEQUIPMENT POINT COUNT
171.442 170 275 MEMORY 1
171.454 186 423 AUTOM. 5-SPEED TRANS. 4
171.445 170 424 SEQUENTRONIC 1
481 UNDERBODY PROTECTION 2
171.454 186 523-530 RADIO/COMAND/NAVIGATION 1
580/581 AUTOMATIC AIR CONDITIONING 4
171.456 190 600 HEADLAMP CLEANING SYSTEM 1
614/618 BI-XENON LIGHT 1
171.458 190 673 BATTERY WITH HIGHER CAPACITY 2
810 SOUND SYSTEM 1
171.473 203 873 SEAT HEATER 1
875 HEATED HEADLAMP CLEANING SYSTEM 1
==============================================================================================================================
SUM OF POINTS... TABLE, FRONT.. SPR. - SERIES
442/445 454/456/458/473
-173 -180 A171 321 03 04
174-183 181-185 A171 321 04 04
184-192 186-193 A171 321 05 04
193-250 194-250 A171 321 09 04
================================================================================================-=============================
TABLE, FRONT.. SPRING - 486 (SPORTS SUS.)
442/445 454/456/458/473
-179 -180 A171 321 06 04
180-184 181-185 A171 321 07 04
185-193 186-193 A171 321 08 04
194-250 194-250 A171 321 10 04
=============================================================================================================================
Description: Color marking: 1 x white/1 x brown.
MSRP $87.00
$63.44
MSRP $87.00
$63.44
30
Helical Spring Mercedes-Benz
Mercedes-Benz Notes: IN ORDER TO DETERMINE THE FRONT SPRINGS THE POINTS IN THE FOLLOWING TABLE FOR THE RESPECTIVE MODEL SERIES AND THE
SPECIAL VERSION AS INSTALLED ARE TO BE ADDED UP
==============================================================================================================================
MODEL DESIGN. POINT COUNT CODE SPECIALEQUIPMENT POINT COUNT
171.442 170 275 MEMORY 1
171.454 186 423 AUTOM. 5-SPEED TRANS. 4
171.445 170 424 SEQUENTRONIC 1
481 UNDERBODY PROTECTION 2
171.454 186 523-530 RADIO/COMAND/NAVIGATION 1
580/581 AUTOMATIC AIR CONDITIONING 4
171.456 190 600 HEADLAMP CLEANING SYSTEM 1
614/618 BI-XENON LIGHT 1
171.458 190 673 BATTERY WITH HIGHER CAPACITY 2
810 SOUND SYSTEM 1
171.473 203 873 SEAT HEATER 1
875 HEATED HEADLAMP CLEANING SYSTEM 1
==============================================================================================================================
SUM OF POINTS... TABLE, FRONT.. SPR. - SERIES
442/445 454/456/458/473
-173 -180 A171 321 03 04
174-183 181-185 A171 321 04 04
184-192 186-193 A171 321 05 04
193-250 194-250 A171 321 09 04
================================================================================================-=============================
TABLE, FRONT.. SPRING - 486 (SPORTS SUS.)
442/445 454/456/458/473
-179 -180 A171 321 06 04
180-184 181-185 A171 321 07 04
185-193 186-193 A171 321 08 04
194-250 194-250 A171 321 10 04
=============================================================================================================================
Description: Color marking: 1 x yellowith 2 x blue.
MSRP $152.00
$111.02
MSRP $152.00
$111.02
30
Helical Spring Mercedes-Benz
Mercedes-Benz Description: Color marking: 2 x yellowith 1 x orange.
MSRP $152.00
$111.02
MSRP $152.00
$111.02
30
Helical Spring Mercedes-Benz
Mercedes-Benz Notes: IN ORDER TO DETERMINE THE FRONT SPRINGS THE POINTS IN THE FOLLOWING TABLE FOR THE RESPECTIVE MODEL SERIES AND THE
SPECIAL VERSION AS INSTALLED ARE TO BE ADDED UP
==============================================================================================================================
MODEL DESIGN. POINT COUNT CODE SPECIALEQUIPMENT POINT COUNT
171.442 170 275 MEMORY 1
171.454 186 423 AUTOM. 5-SPEED TRANS. 4
171.445 170 424 SEQUENTRONIC 1
481 UNDERBODY PROTECTION 2
171.454 186 523-530 RADIO/COMAND/NAVIGATION 1
580/581 AUTOMATIC AIR CONDITIONING 4
171.456 190 600 HEADLAMP CLEANING SYSTEM 1
614/618 BI-XENON LIGHT 1
171.458 190 673 BATTERY WITH HIGHER CAPACITY 2
810 SOUND SYSTEM 1
171.473 203 873 SEAT HEATER 1
875 HEATED HEADLAMP CLEANING SYSTEM 1
==============================================================================================================================
SUM OF POINTS... TABLE, FRONT.. SPR. - SERIES
442/445 454/456/458/473
-173 -180 A171 321 03 04
174-183 181-185 A171 321 04 04
184-192 186-193 A171 321 05 04
193-250 194-250 A171 321 09 04
================================================================================================-=============================
TABLE, FRONT.. SPRING - 486 (SPORTS SUS.)
442/445 454/456/458/473
-179 -180 A171 321 06 04
180-184 181-185 A171 321 07 04
185-193 186-193 A171 321 08 04
194-250 194-250 A171 321 10 04
=============================================================================================================================
Description: Color marking: 1 x white/1 x red.
30
Helical Spring Mercedes-Benz
Mercedes-Benz Notes: IN ORDER TO DETERMINE THE FRONT SPRINGS THE POINTS IN THE FOLLOWING TABLE FOR THE RESPECTIVE MODEL SERIES AND THE
SPECIAL VERSION AS INSTALLED ARE TO BE ADDED UP
==============================================================================================================================
MODEL DESIGN. POINT COUNT CODE SPECIALEQUIPMENT POINT COUNT
171.442 170 275 MEMORY 1
171.454 186 423 AUTOM. 5-SPEED TRANS. 4
171.445 170 424 SEQUENTRONIC 1
481 UNDERBODY PROTECTION 2
171.454 186 523-530 RADIO/COMAND/NAVIGATION 1
580/581 AUTOMATIC AIR CONDITIONING 4
171.456 190 600 HEADLAMP CLEANING SYSTEM 1
614/618 BI-XENON LIGHT 1
171.458 190 673 BATTERY WITH HIGHER CAPACITY 2
810 SOUND SYSTEM 1
171.473 203 873 SEAT HEATER 1
875 HEATED HEADLAMP CLEANING SYSTEM 1
==============================================================================================================================
SUM OF POINTS... TABLE, FRONT.. SPR. - SERIES
442/445 454/456/458/473
-173 -180 A171 321 03 04
174-183 181-185 A171 321 04 04
184-192 186-193 A171 321 05 04
193-250 194-250 A171 321 09 04
================================================================================================-=============================
TABLE, FRONT.. SPRING - 486 (SPORTS SUS.)
442/445 454/456/458/473
-179 -180 A171 321 06 04
180-184 181-185 A171 321 07 04
185-193 186-193 A171 321 08 04
194-250 194-250 A171 321 10 04
=============================================================================================================================
Description: Color marking: 1 x yellowith 1 x orange.
30
Helical Spring Mercedes-Benz
Mercedes-Benz Notes: IN ORDER TO DETERMINE THE FRONT SPRINGS THE POINTS IN THE FOLLOWING TABLE FOR THE RESPECTIVE MODEL SERIES AND THE
SPECIAL VERSION AS INSTALLED ARE TO BE ADDED UP
==============================================================================================================================
MODEL DESIGN. POINT COUNT CODE SPECIALEQUIPMENT POINT COUNT
171.442 170 275 MEMORY 1
171.454 186 423 AUTOM. 5-SPEED TRANS. 4
171.445 170 424 SEQUENTRONIC 1
481 UNDERBODY PROTECTION 2
171.454 186 523-530 RADIO/COMAND/NAVIGATION 1
580/581 AUTOMATIC AIR CONDITIONING 4
171.456 190 600 HEADLAMP CLEANING SYSTEM 1
614/618 BI-XENON LIGHT 1
171.458 190 673 BATTERY WITH HIGHER CAPACITY 2
810 SOUND SYSTEM 1
171.473 203 873 SEAT HEATER 1
875 HEATED HEADLAMP CLEANING SYSTEM 1
==============================================================================================================================
SUM OF POINTS... TABLE, FRONT.. SPR. - SERIES
442/445 454/456/458/473
-173 -180 A171 321 03 04
174-183 181-185 A171 321 04 04
184-192 186-193 A171 321 05 04
193-250 194-250 A171 321 09 04
================================================================================================-=============================
TABLE, FRONT.. SPRING - 486 (SPORTS SUS.)
442/445 454/456/458/473
-179 -180 A171 321 06 04
180-184 181-185 A171 321 07 04
185-193 186-193 A171 321 08 04
194-250 194-250 A171 321 10 04
=============================================================================================================================
Description: Color marking: 1 x yellowith 1 x brown.
70
Nut Mercedes-Benz
Mercedes-Benz Description: Spring strut to body. M8
Diameter: 8mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1,25mm
Outside diameter: 17,9mm
Width across flats: 13mm. Suspension strut to body. Torsion bar on body.
Diameter: 8mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1,25mm
Outside diameter: 17,9mm
Width across flats: 13mm. Suspension strut to body. Torsion bar on body.
90
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: Lower control arm to front subframe. Shock absorber to frame. Lower control arm to steering knuckle.
100
Hexalobular Head Screw Mercedes-Benz
Mercedes-Benz Description: Hydropneumatic spring leg to steering knuckle,top. M14x1.5x45. Suspension strut to upper steering knuckle. Damper strut to steering knuckle.
MSRP $14.00
$10.41
MSRP $14.00
$10.41
110
Hex Nut W Flange + Piece Mercedes-Benz
Mercedes-Benz Description: Hydropneumatic spring leg to steering knuckle,top. M14x1.5. Damper strut to steering knuckle m 14x1.5. Suspension strut to upper steering knuckle.
MSRP $5.50
$4.19
MSRP $5.50
$4.19
120
Hexagon Head Screw Mercedes-Benz
Mercedes-Benz Description: Hydropneumatic spring leg to steering knuckle,bottom. Damper strut to steering knuckle, bottom m12x1,5x 16. Shock absorber to steering knuckle, bottom.
MSRP $4.90
$3.68
MSRP $4.90
$3.68
130
Window Mercedes-Benz
Mercedes-Benz Description: Hydropneumatic spring leg to steering knuckle,bottom. Fastening seatbelt buckle left. Damper strut to steering knuckle, bottom.
MSRP $6.50
$4.83
MSRP $6.50
$4.83
