Rear Springs and Suspension Used with Self-Levelling Device for 1999 Mercedes-Benz E430
No.
Part # / Description / Price
Price
5
Rear Spring
Mercedes-Benz
Mercedes-Benz Notes: UPON EXCHANGING SPRING, ALWAYS REPLACE LOWER SPRING SEAL
TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 210.020 30 414 SLIDING ROOF 3 210.025 35 TELEPHONE 1 210.055 33 810 SOUND SYSTEM 1 210.065 40 540 ROLLER BLIND 1 210.070 46 CD CHANGER 1 210.072 E50AMG 40 210.074 E55AMG 33 210.082 40 ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -34 210 324 32 04 210 325 03 84 35-40 210 324 32 04 210 325 04 84 . 41-47 210 324 33 04 210 325 01 84 48-54 210 324 33 04 210 325 02 84 55-60 210 324 33 04 210 325 03 84 61- 210 324 33 04 210 325 04 84 . 40-42 210 324 18 04 210 325 01 84 43-50 210 324 18 04 210 325 02 84 51-57 210 324 18 04 210 325 03 84 58- 210 324 18 04 210 325 04 84 ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -31 210 324 31 04 210 325 03 84 32-37 210 324 31 04 210 325 04 84 . 38-44 210 324 17 04 210 325 01 84 45-50 210 324 17 04 210 325 02 84 51- 210 324 17 04 210 325 03 84 . ==============================================================================================================================
TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 210.020 30 414 SLIDING ROOF 3 210.025 35 TELEPHONE 1 210.055 33 810 SOUND SYSTEM 1 210.065 40 540 ROLLER BLIND 1 210.070 46 CD CHANGER 1 210.072 E50AMG 40 210.074 E55AMG 33 210.082 40 ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -34 210 324 32 04 210 325 03 84 35-40 210 324 32 04 210 325 04 84 . 41-47 210 324 33 04 210 325 01 84 48-54 210 324 33 04 210 325 02 84 55-60 210 324 33 04 210 325 03 84 61- 210 324 33 04 210 325 04 84 . 40-42 210 324 18 04 210 325 01 84 43-50 210 324 18 04 210 325 02 84 51-57 210 324 18 04 210 325 03 84 58- 210 324 18 04 210 325 04 84 ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -31 210 324 31 04 210 325 03 84 32-37 210 324 31 04 210 325 04 84 . 38-44 210 324 17 04 210 325 01 84 45-50 210 324 17 04 210 325 02 84 51- 210 324 17 04 210 325 03 84 . ==============================================================================================================================
Description: As required. Color marking: 1 x blue/2 x yellow.
5
Rear Spring Mercedes-Benz
Mercedes-Benz Notes: UPON EXCHANGING SPRING, ALWAYS REPLACE LOWER SPRING SEAL
Description: Color marking: 1 x green/3 x red.
5
Rear Spring Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
UPON EXCHANGING SPRING, ALWAYS REPLACE LOWER SPRING SEAL
TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 210.020 30 414 SLIDING ROOF 3 210.025 35 TELEPHONE 1 210.055 33 810 SOUND SYSTEM 1 210.065 40 540 ROLLER BLIND 1 210.070 46 CD CHANGER 1 210.072 E50AMG 40 210.074 E55AMG 33 210.082 40 ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -34 210 324 32 04 210 325 03 84 35-40 210 324 32 04 210 325 04 84 . 41-47 210 324 33 04 210 325 01 84 48-54 210 324 33 04 210 325 02 84 55-60 210 324 33 04 210 325 03 84 61- 210 324 33 04 210 325 04 84 . 40-42 210 324 18 04 210 325 01 84 43-50 210 324 18 04 210 325 02 84 51-57 210 324 18 04 210 325 03 84 58- 210 324 18 04 210 325 04 84 ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -31 210 324 31 04 210 325 03 84 32-37 210 324 31 04 210 325 04 84 . 38-44 210 324 17 04 210 325 01 84 45-50 210 324 17 04 210 325 02 84 51- 210 324 17 04 210 325 03 84 . ==============================================================================================================================
UPON EXCHANGING SPRING, ALWAYS REPLACE LOWER SPRING SEAL
TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 210.020 30 414 SLIDING ROOF 3 210.025 35 TELEPHONE 1 210.055 33 810 SOUND SYSTEM 1 210.065 40 540 ROLLER BLIND 1 210.070 46 CD CHANGER 1 210.072 E50AMG 40 210.074 E55AMG 33 210.082 40 ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -34 210 324 32 04 210 325 03 84 35-40 210 324 32 04 210 325 04 84 . 41-47 210 324 33 04 210 325 01 84 48-54 210 324 33 04 210 325 02 84 55-60 210 324 33 04 210 325 03 84 61- 210 324 33 04 210 325 04 84 . 40-42 210 324 18 04 210 325 01 84 43-50 210 324 18 04 210 325 02 84 51-57 210 324 18 04 210 325 03 84 58- 210 324 18 04 210 325 04 84 ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -31 210 324 31 04 210 325 03 84 32-37 210 324 31 04 210 325 04 84 . 38-44 210 324 17 04 210 325 01 84 45-50 210 324 17 04 210 325 02 84 51- 210 324 17 04 210 325 03 84 . ==============================================================================================================================
Description: Color marking: 2 x yellowith 1 x white.
8
Rubber Boot Mercedes-Benz
Mercedes-Benz Notes: TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
210.020 30 414 SLIDING ROOF 3
210.025 35 TELEPHONE 1
210.055 33 810 SOUND SYSTEM 1
210.065 40 540 ROLLER BLIND 1
210.070 46 CD CHANGER 1
210.072 E50AMG 40
210.074 E55AMG 33
210.082 40
==============================================================================================================================
CHART OF REAR SPRING RUBBER PADS
==============================================================================================================================
TOTAL OF POINTS REAR SPRING PAD
-34 210 324 32 04 210 325 03 84
35-40 210 324 32 04 210 325 04 84
.
41-47 210 324 33 04 210 325 01 84
48-54 210 324 33 04 210 325 02 84
55-60 210 324 33 04 210 325 03 84
61- 210 324 33 04 210 325 04 84
.
40-42 210 324 18 04 210 325 01 84
43-50 210 324 18 04 210 325 02 84
51-57 210 324 18 04 210 325 03 84
58- 210 324 18 04 210 325 04 84
==============================================================================================================================
CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480
==============================================================================================================================
TOTAL OF POINTS REAR SPRING PAD
-31 210 324 31 04 210 325 03 84
32-37 210 324 31 04 210 325 04 84
.
38-44 210 324 17 04 210 325 01 84
45-50 210 324 17 04 210 325 02 84
51- 210 324 17 04 210 325 03 84
.
==============================================================================================================================
Description: Upper. stud quantity: 2 (9mm). Top. Stud count: 2 (9mm). As required. Number of burls: 2 (9 mm).
MSRP $6.50
$4.95
MSRP $6.50
$4.95
8
Rubber Boot Mercedes-Benz
Mercedes-Benz Notes: TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
210.020 30 414 SLIDING ROOF 3
210.025 35 TELEPHONE 1
210.055 33 810 SOUND SYSTEM 1
210.065 40 540 ROLLER BLIND 1
210.070 46 CD CHANGER 1
210.072 E50AMG 40
210.074 E55AMG 33
210.082 40
==============================================================================================================================
CHART OF REAR SPRING RUBBER PADS
==============================================================================================================================
TOTAL OF POINTS REAR SPRING PAD
-34 210 324 32 04 210 325 03 84
35-40 210 324 32 04 210 325 04 84
.
41-47 210 324 33 04 210 325 01 84
48-54 210 324 33 04 210 325 02 84
55-60 210 324 33 04 210 325 03 84
61- 210 324 33 04 210 325 04 84
.
40-42 210 324 18 04 210 325 01 84
43-50 210 324 18 04 210 325 02 84
51-57 210 324 18 04 210 325 03 84
58- 210 324 18 04 210 325 04 84
==============================================================================================================================
CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480
==============================================================================================================================
TOTAL OF POINTS REAR SPRING PAD
-31 210 324 31 04 210 325 03 84
32-37 210 324 31 04 210 325 04 84
.
38-44 210 324 17 04 210 325 01 84
45-50 210 324 17 04 210 325 02 84
51- 210 324 17 04 210 325 03 84
.
==============================================================================================================================
Description: Upper. stud quantity: 3 (13mm). Top. Stud count: 3 (13mm). As required. Number of burls: 3 (13 mm).
MSRP $8.75
$6.60
MSRP $8.75
$6.60
8
Rubber Boot Mercedes-Benz
Mercedes-Benz Notes: TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
210.020 30 414 SLIDING ROOF 3
210.025 35 TELEPHONE 1
210.055 33 810 SOUND SYSTEM 1
210.065 40 540 ROLLER BLIND 1
210.070 46 CD CHANGER 1
210.072 E50AMG 40
210.074 E55AMG 33
210.082 40
==============================================================================================================================
CHART OF REAR SPRING RUBBER PADS
==============================================================================================================================
TOTAL OF POINTS REAR SPRING PAD
-34 210 324 32 04 210 325 03 84
35-40 210 324 32 04 210 325 04 84
.
41-47 210 324 33 04 210 325 01 84
48-54 210 324 33 04 210 325 02 84
55-60 210 324 33 04 210 325 03 84
61- 210 324 33 04 210 325 04 84
.
40-42 210 324 18 04 210 325 01 84
43-50 210 324 18 04 210 325 02 84
51-57 210 324 18 04 210 325 03 84
58- 210 324 18 04 210 325 04 84
==============================================================================================================================
CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480
==============================================================================================================================
TOTAL OF POINTS REAR SPRING PAD
-31 210 324 31 04 210 325 03 84
32-37 210 324 31 04 210 325 04 84
.
38-44 210 324 17 04 210 325 01 84
45-50 210 324 17 04 210 325 02 84
51- 210 324 17 04 210 325 03 84
.
==============================================================================================================================
Description: Top. Stud count: 4 (17mm). As required. Number of burls: 4 (17 mm). Upper. stud quantity: 4 ( 17MM).
MSRP $8.75
$6.67
MSRP $8.75
$6.67
8
Spring Retainer Insert Mercedes-Benz
Mercedes-Benz Notes: TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
210.020 30 414 SLIDING ROOF 3
210.025 35 TELEPHONE 1
210.055 33 810 SOUND SYSTEM 1
210.065 40 540 ROLLER BLIND 1
210.070 46 CD CHANGER 1
210.072 E50AMG 40
210.074 E55AMG 33
210.082 40
==============================================================================================================================
CHART OF REAR SPRING RUBBER PADS
==============================================================================================================================
TOTAL OF POINTS REAR SPRING PAD
-34 210 324 32 04 210 325 03 84
35-40 210 324 32 04 210 325 04 84
.
41-47 210 324 33 04 210 325 01 84
48-54 210 324 33 04 210 325 02 84
55-60 210 324 33 04 210 325 03 84
61- 210 324 33 04 210 325 04 84
.
40-42 210 324 18 04 210 325 01 84
43-50 210 324 18 04 210 325 02 84
51-57 210 324 18 04 210 325 03 84
58- 210 324 18 04 210 325 04 84
==============================================================================================================================
CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480
==============================================================================================================================
TOTAL OF POINTS REAR SPRING PAD
-31 210 324 31 04 210 325 03 84
32-37 210 324 31 04 210 325 04 84
.
38-44 210 324 17 04 210 325 01 84
45-50 210 324 17 04 210 325 02 84
51- 210 324 17 04 210 325 03 84
.
==============================================================================================================================
Description: Upper. stud quantity: 1 (5mm). Top. Stud count: 1 (5mm). As required. Number of burls: 1 (5 mm).
MSRP $6.00
$4.57
MSRP $6.00
$4.57
9
MSRP $15.00
$11.43
14
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: M10X60
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Engine mounting to engine support. Pitman arm to steering box assembly. Engine mount to engine carrier. Hydropneumatic spring leg to spring control arm. Shock absorber to lower control arm. Shock absorber to spring control arm.
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Engine mounting to engine support. Pitman arm to steering box assembly. Engine mount to engine carrier. Hydropneumatic spring leg to spring control arm. Shock absorber to lower control arm. Shock absorber to spring control arm.
MSRP $6.25
$4.70
MSRP $6.25
$4.70
14
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Shock absorber to spring control arm. M10x70. Hydropneumatic spring leg to spring control arm. Strut at left holder.
17
Washer Mercedes-Benz
Mercedes-Benz Description: Refrigerant compressor to support. Bearing cup to bearing bracket.
MSRP $2.70
$2.03
MSRP $2.70
$2.03
20
Nut Mercedes-Benz
Mercedes-Benz Description: Hydropneumatic spring leg to spring control arm. Shock absorber to lower control arm. Shock absorber to spring control arm.
23
26
Rubber Bumper Mercedes-Benz
Mercedes-Benz Description: Hydropneumatic spring leg to frame. Bumper to body.
MSRP $22.50
$17.15
MSRP $22.50
$17.15
29
Rubber Bumper Mercedes-Benz
Mercedes-Benz Description: Hydropneumatic spring leg to frame. Shock absorber to frame. Bumper to body.
32
Window Mercedes-Benz
Mercedes-Benz Description: Shock absorber to frame. Bumper to body. Hydropneumatic spring leg to frame. Shock absorber to rear axle.
MSRP $3.70
$2.79
MSRP $3.70
$2.79
35
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: M10X1
Diameter: 10mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1mm
Width across flats: 16mm. Front shock absorbers to frame. Bumper to body. Shock absorber to frame m 10x1. Hydropneumatic spring leg to frame m 10x1.
Diameter: 10mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1mm
Width across flats: 16mm. Front shock absorbers to frame. Bumper to body. Shock absorber to frame m 10x1. Hydropneumatic spring leg to frame m 10x1.
MSRP $3.70
$2.79
MSRP $3.70
$2.79
