Cockpit Cable Harness for 1999 Mercedes-Benz CLK430

Description: Operating unit of tempmatik/automatic air conditioner 29polig. 29-pin. Operating unit of tempmatik/automatic air conditioner code 580/581, 29 polig. 29-pin. To 000 545 34 30. 000 545 35 30. 29-pin.

View Details

14

Cover

000-545-34-30

Mercedes-Benz

Description: Operating unit of tempmatik/automatic air conditioner. Control module air conditioning.

View Details

17

Cover

000-545-35-30

Mercedes-Benz

Description: Operating unit of tempmatik/automatic air conditioner. To 001 545 28 40. Air conditioning automatics operating unit.

View Details

20

5458503 - Electrical Equipment and Instruments: Cap for Mercedes-Benz Image

Cap

000-545-85-03

Mercedes-Benz

Description: To 001 545 28 40. To 000 545 34 30. 000 545 35 30.

View Details

23

Contact Spring

008-545-50-26

Mercedes-Benz

Description: 0,35MM. 0.5-1.0 MM2 E95Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: E95Release tool: W220 589 01 99 55. 0,5-1,0 MM. 0.5-1.0 MM2 E95Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: E95Relea ...

MSRP $5.00

$3.80

MSRP $5.00

$3.80

35

Receptacle Housing

029-545-55-28

Mercedes-Benz

MSRP $2.90

$2.16

MSRP $2.90

$2.16

38

Contact Support

208-545-08-40

Mercedes-Benz

Description: "sam" control unit rear. 14-pin mqs
model 1: mqs
slots: 14. Light rotary switch. 14-pin mqs
model 1: mqs
slots: 14. Drive unit control unit n145*1. 14-pin mqs
model 1: mqs
slots: 14. Control unit multi-contour backrest. 14-pin mqs
model 1: mqs
slots: 14. Control unit, electronic ignition lock. 14-pin mqs
model 1: mqs
slots: 14.

MSRP $3.70

$2.79

MSRP $3.70

$2.79

41

Housing

208-545-08-30

Mercedes-Benz

Description: To 208 545 08 40.

View Details

47

Plug

168-545-03-28

Mercedes-Benz

Notes: NOT YET AVAILABLE

Description: Clock spring contact horn. 4-pin mqs. Contact spiral. 4-pin mqs.

View Details

50

Plug

032-545-52-28

Mercedes-Benz

Description: Gear recognition S16/10. 8-PIN. Gear recognition switch s17/10. 8-pin. Outside rearview mirror code b. 8-pin. Sam control unit. 8-pin. Relay cluster. 8-pin.

View Details

53

Receptacle Housing

001-545-40-40

Mercedes-Benz

Description: Instrument cluster 18-polig. 18-pin.

View Details

56

Plug

032-545-84-28

Mercedes-Benz

Description: Front passenger fuse and relay box, white. 12-pin. Srb fahrer, c4. 12-pin.

View Details

59

Plug

032-545-86-28

Mercedes-Benz

Description: Fuse and relay box,driver 12 polig. 12-pin. Passenger fuse and relay boxes, violet. 12-pin. Srb fahrer, c3. 12-pin.

View Details

62

Contact Socket

008-545-55-26

Mercedes-Benz

Description: 0.75mm2. 0.75 MM2
Leitungsquerschnitt Min/Max: 0,5-0,75mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MQS.

MSRP $5.25

$3.94

MSRP $5.25

$3.94

68

Receptacle Housing

029-545-53-28

Mercedes-Benz

Description: Left/right entrance/ex it lamp. 2 pin jpt. Luggage compartment lamp. 2 pin jpt. Glove compartment lamp. 2 pin jpt. Glove box lamp E13/1. 2 PIN JPT. Driver and front passenger footwell lamp e17/15, e17/16. 2 pin jpt. Left exit lights. 2 pin jpt. Courtesy lamp. 2 pin jpt. Interface. 2 pin jpt. Glove compartment lighting e13/2. 2 pin jpt. Vanity mirror illumination e14/6 e14/7. 2 pin jpt.

MSRP $3.40

$2.54

MSRP $3.40

$2.54

71

Plug

038-545-76-28

Mercedes-Benz

Description: Keyless-go control module n 69/5. 10-pin slk2.8. Signal acquisition and actuation module, passenger side code b, n10. 10-pin slk2.8. Keyless-go n69/5. 10-pin slk2.8. Exterior light switch module. 10-pin slk2.8.

MSRP $6.50

$4.83

MSRP $6.50

$4.83

74

Plug

208-545-08-28

Mercedes-Benz

Description: Combination switch,6-pole. 6-pin. Control unit. 6-pin. Combination switch plug-connection. 6-pin.

View Details

77

Receptacle Housing

210-545-42-28

Mercedes-Benz

Description: Dome lamp, delay. 5-pin jpt. Airbag, passenger side. 5-pin jpt. Tail lamp. 5-pin jpt. Control unit, steering lock. 5-pin jpt. Electric steering lock. 5-pin jpt.

MSRP $3.40

$2.54

MSRP $3.40

$2.54

80

Plug

208-545-00-28

Mercedes-Benz

Description: Electronic ignition switch controlunit n73. 6-pin. Ignition/starter switch, 6-pin. 6-pin. Control unit, electronic ignition lock. 6-pin. Starting ignition switch n73. 6-pin.

View Details

83

Plug

210-545-57-28

Mercedes-Benz

Description: Light switch module. 4-pin. Light rotary switch. 4-pin.

View Details

86

Contact Spring

011-545-81-26

Mercedes-Benz

Description: Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.

MSRP $3.50

$2.67

MSRP $3.50

$2.67

86

Electric Line

000-540-37-05

Mercedes-Benz

Description: FAN MOTOR M4/3. 6.0 MM2 LSK8 AGLeitungsquerschnitt Min/Max: 6,0mm2Oberflächenschutz PINs: AgModel 1: LSKModel 2: 8Release tool: W220 589 01 99 56. FLAT PLUG 4.0 - 6.0 MM2. 6.0 MM2 LSK8 AGLeitungsquerschnitt Min/Max: 6,0mm2Oberflächenschutz PINs: AgModel ...

MSRP $18.50

$13.97

MSRP $18.50

$13.97

86

115458026 - Electrical Equipment and Instruments: Contact Spring for Mercedes-Benz Image

Spring Retaining Pin

011-545-80-26

Mercedes-Benz

Description: 1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.

MSRP $3.90

$2.92

MSRP $3.90

$2.92

87

Receptacle Housing

032-545-19-28

Mercedes-Benz

MSRP $3.40

$2.54

MSRP $3.40

$2.54

87

Receptacle Housing

032-545-24-28

Mercedes-Benz

Description: Ashtray lighting in the rear. 2-pin mqs. Ignition lock. 2-pin mqs.

MSRP $2.70

$2.03

MSRP $2.70

$2.03

89

Receptacle Housing

014-545-00-28

Mercedes-Benz

Description: At lf outlet. 3-pin. 3-pole. 3-pin. Heat exchanger temperature sensor 3 polig. 3-pin. Temperature sensor,heat exchanger, three-pin. 3-pin. Valve strip. 3-pin.

View Details

92

Coupling, Mechanical

011-545-51-28

Mercedes-Benz

Description: Automatic antenna. 4-pin rk2.5. Valve strip. Fourpole. 4-pin rk2.5. Tempmatik control box. 6-pole. 4-pin rk2.5. Inboard feeler blower. 4-pin rk2.5. Electrical antenna,6-pole. 4-pin rk2.5. Ventilation blower. 4-pin rk2.5. Pre-glow time relay. 4-pole. 4-pin rk2.5.

View Details

95

Contact Socket

002-545-99-26

Mercedes-Benz

Description: 2.5 M. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. TO 201 540 02 81. 0.35-2.5 MM2 RK2.5Leitungsquerschni ...

MSRP $2.70

$2.03

MSRP $2.70

$2.03

98

Receptacle Housing

012-545-86-28

Mercedes-Benz

MSRP $4.20

$3.18

MSRP $4.20

$3.18

101

Contact Socket

003-545-06-26

Mercedes-Benz

Description: 4 MM. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. 2,5 (AX). 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Ma ...

MSRP $2.90

$2.16

MSRP $2.90

$2.16

104

Electric Coupling

012-545-24-28

Mercedes-Benz

Notes: NO LONGER AVAILABLE

View Details

107

Contact Socket

003-545-26-26

Mercedes-Benz

Description: 4.0mm2.

MSRP $3.70

$2.82

MSRP $3.70

$2.82

110

Plug Housing

035-545-27-28

Mercedes-Benz

Description: Plug connection 4 polig, (motorraum/cockpit). 4-pin. Tail lamp cable harness plugconnection. 4-pin. Engine plug connection cockpit. 4-pin.

View Details

113

Contact Pin

033-545-19-28

Mercedes-Benz

Description: 207. 0.5-1.0 MM2 RK2.5
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DIA
Model 2: 2.5. RPM SENSOR 0,5-1,0mm2. 0.5-1.0 MM2 RK2.5
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DIA
Model 2: 2.5. 0,5-1,0 MM. 0.5-1.0 MM2 RK2.5
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DIA
Model 2: 2.5.

MSRP $2.70

$2.03

MSRP $2.70

$2.03

116

Receptacle Housing

012-545-31-28

Mercedes-Benz

Description: Dome lamp;3-pole. 3-pin. Cigar lighter. 3-pin. Rear dome lamp. 3-pin.

View Details

119

Receptacle

000-546-79-40

Mercedes-Benz

Description: 756. 1.0-2.5 mm2 ff6.3. Radio. 1.0-2.5 mm2 ff6.3. Engine hood. 1.0-2.5 mm2 ff6.3. Parking brake switch. 1.0-2.5 mm2 ff6.3.

View Details

122

Plug Housing

031-545-78-28

Mercedes-Benz

Notes: NO LONGER AVAILABLE

Description: Cockpit cable harness. 2-pin rk2.5. Microphone. 2-pin rk2.5. Tail lamp cable harness plugconnection schwarz. 2-pin rk2.5.

View Details

125

Contact Socket

009-545-29-26

Mercedes-Benz

Description: 0.5-1.0MM2 . 1.1-2.5 MM2 RK2.5
Leitungsquerschnitt Min/Max: 1,1-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: RK
Model 2: 2.5
Release tool: W220 589 01 99 30 / W220 589 01 99 53
Crimp tool: W220 589 01 99 06. 1.0 - 2.5 MM2. 1.1-2.5 MM2 RK2.5
Leitungsquerschnitt Min/Max: 1,1-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: RK
Model 2: 2.5
Release tool: W220 589 01 99 30 / W220 589 01 99 53
Crimp tool: W220 589 01 99 06.

MSRP $1.90

$1.40

MSRP $1.90

$1.40

128

Plug

032-545-95-28

Mercedes-Benz

Description: Fuse and relay box,driver 4 polig. 4-pin. Front fuse and relay box. 4-pin. Srb/fahrer, c1. 4-pin.

View Details

131

Plug

032-545-89-28

Mercedes-Benz

Description: Fuse and relay box,driver 2 polig. 2-pin. Relay unit. 2-pin. Srb/fahrer, c2. 2-pin.

View Details

134

Electric Line

000-540-35-05

Mercedes-Benz

Description: Tin-plated. 1.5 MM2 WDF2Leitungsquerschnitt Min/Max: 1,5mm2Oberflächenschutz PINs: SnModel 1: WDF2. GLOVE COMPARTMENT LIGHTING E13/1. 1.5 MM2 WDF2Leitungsquerschnitt Min/Max: 1,5mm2Oberflächenschutz PINs: SnModel 1: WDF2. CIGAR LIGHTER R3. 1.5 MM2 WDF2Le ...

MSRP $15.00

$11.30

MSRP $15.00

$11.30

134

Contact Socket

004-545-00-26

Mercedes-Benz

MSRP $2.50

$1.91

MSRP $2.50

$1.91

134

Contact Spring

004-545-52-26

Mercedes-Benz

Description: Fuse and relay module, driver k40/2. Fuse and relay module, front passenger k40/4. FUSE AND RELAY BOX,DRIVER. 1.0-2.5 MM2 SPT
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.

MSRP $4.90

$3.68

MSRP $4.90

$3.68

137

Pin Housing

036-545-23-28

Mercedes-Benz

Description: Intermediate connector, airbag. 2-pin. Door separation point,b-pillar. 2-pin. Belt locking retractor plug-connection. 2-pin. Co-driver's air bag. 2-pin.

View Details

140

Plug Pin

011-545-16-28

Mercedes-Benz

MSRP $2.50

$1.91

MSRP $2.50

$1.91

143

Contact Spring

008-545-82-26-64

Mercedes-Benz

Description: 0.35-1.5 mm. 0.35-1.0 mm2, 1polig.

MSRP $4.50

$3.43

MSRP $4.50

$3.43

146

8545802664 - Electrical Equipment and Instruments: Contact for Mercedes-Benz Image

Spring Retaining Pin

008-545-80-26-64

Mercedes-Benz

Description: 0.35.1.0 mm2. 1.5-2.5 mm2,1 polig. Unipolar. 1.5-2.5 mm2, 1polig. 1.5-2.5mm2.

MSRP $4.00

$3.05

MSRP $4.00

$3.05

149

8545792664 - Electrical Equipment and Instruments: Contact Spring for Mercedes-Benz Image

Spring Retaining Pin

008-545-79-26-64

Mercedes-Benz

Description: FUSE BOX 2.5-4.0 MM2, 1POLIG. 1-PIN 2.5-4.0 MM2 GSK
Leitungsquerschnitt Min/Max: 2,5-4,0mm2
Oberflächenschutz PINs: blank
ELA: -
Model 1: GSK.

MSRP $3.70

$2.79

MSRP $3.70

$2.79

152
