Refrigerant Line Arrangement for 1996 Mercedes-Benz SL320
No.
Part # / Description / Price
Price
30
MSRP $4.30
$3.28
35
Grommet
Mercedes-Benz
Mercedes-Benz Description: From expansion valve to compressor. Return line thru fire wall. Feed line to fire wall. For fuel hose through wall, spare wheel recess. For starter cable through partition wall. (starter cable through pedal floor). (to seal vacuum connection at ate booster brake). Hose thru fire wall.
55
MSRP $65.00
$47.36
60
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Heater. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. HEATING. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. MOUNTING PLATE TO DRI ...
MSRP $3.70
$2.79
MSRP $3.70
$2.79
65
Mounting Clamp Mercedes-Benz
Mercedes-Benz Description: Regeneration line to left front wheel arch. 10/15. Vent hose to activated charcoal filter. 10/15. Oil line to engine. 10/15.
MSRP $9.50
$7.24
MSRP $9.50
$7.24
65
Clamp Mercedes-Benz
Mercedes-Benz Description: Vent hose to activated charcoal filter. 10/15 mm. Pipe line to cross member. 10/15 mm. Vent line to left side member,outside. 10/15 mm.
75
MSRP $60.00
$44.28
90
MSRP $199.00
$139.23
95
Temperature Sensor Mercedes-Benz
Mercedes-Benz Description: At liquid tank,for additional blower. Outdoor temperature sensor.
100
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Pressure switch to liquid tank used for additional blower. 9.0 x 1.8 mm. Pressure switch to liquid tank used for compressor. 9.0 x 1.8 mm. At liquid tank. 9.0 x 1.8 mm. Refrigerant reservoir valve. 9.0 X 1.8 MM. Sensor. 9.0 x 1.8 mm.
105
Protective Cap Mercedes-Benz
Mercedes-Benz Description: Pressure switch to liquid tank used for additional blower. Door contact switch. Front door.
110
Hexagon Head Screw Mercedes-Benz
Mercedes-Benz Description: M5x10.5. At blower;temperature sensor ventilation. Bracket to fire wall. Heat shield mounting. Control unit. Screening plates. Main floor,front right. Return line to partition panel.
MSRP $0.70
$0.51
MSRP $0.70
$0.51
125
Nut Mercedes-Benz
Mercedes-Benz Description: Pipe line to shock absorber leg reinforcement. Pipe line to valve. Hinge lever to engine hood.
130
A/C Line O-Ring Mercedes-Benz
Mercedes-Benz Description: AT CONDENSER. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. PRESSURE LINE TO EXPANSION VALVE. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. Refrigerant li ...
135
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Line to air conditioning system. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOutside diameter: 18mmMaterial thickness: 2mm. TUBING AT EXPANSION VALVE. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOut ...
145
Discharge Line Valve Mercedes-Benz
Mercedes-Benz Description: Condenser. To 140 830 05 70. To 129 830 02 70,129 830 04 70. Filling valve. In pressure line.
MSRP $22.50
$17.13
MSRP $22.50
$17.13
155
MSRP $31.00
$23.50
165
Grommet Mercedes-Benz
Mercedes-Benz Description: Hole plug for vacuum pump. 12 mm. Front left. 12 mm.
MSRP $1.70
$1.27
MSRP $1.70
$1.27
170
Intermediate Layer Mercedes-Benz
Mercedes-Benz Description: Additional blower to condenser. Condenser to radiator.
MSRP $19.50
$14.61
MSRP $19.50
$14.61
185
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Engine hood upper catch to engine hood. Flap to hinge m 6x10.
MSRP $2.90
$2.16
MSRP $2.90
$2.16
190
Bolt And Washer Assembly Mercedes-Benz
Mercedes-Benz Description: Additional blower to additional blower. Auxiliary fan to strut. Oil cooler.
200
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: LEFT GRAB HANDLE MOUNTING
Diameter: 5mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm.
Diameter: 5mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm.
205
MSRP $3.00
$2.29
215
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Amplifier at c-pillar. Amplifier to bracket. Reinforcem. At bracket, left.
MSRP $3.50
$2.67
MSRP $3.50
$2.67
220
MSRP $0.90
$0.64
225
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Feed & return lines to heat exchanger exchanger.
MSRP $1.00
$0.76
MSRP $1.00
$0.76
265
Nut Mercedes-Benz
Mercedes-Benz Description: Blower to cooling module. Condenser and blower to radiator.
MSRP $4.90
$3.68
MSRP $4.90
$3.68
275
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Rear lid to hinge lever. Drive to rear pillar. Pipe line to shock absorber leg reinforcement. Strut to front cross member. Bracket to car floor. Cooling pipe to front cross member. Engine hood upper catch to engine hood. Partition panel. Strut to stiffening,front central.
