Engine Cable Harness, Body Mounted for 1994 Mercedes-Benz E420
No.
Part # / Description / Price
Price
8
MSRP $17.50
$13.34
11
Round Receptacle
Mercedes-Benz
Mercedes-Benz Description: 1MM. 0.35-0.75 MM2 RK1.0Leitungsquerschnitt Min/Max: 0,35-0,75mm2Oberflächenschutz PINs: AuELA: -Model 1: RKModel 2: 1.0. 1,0 MM. 0.35-0.75 MM2 RK1.0Leitungsquerschnitt Min/Max: 0,35-0,75mm2Oberflächenschutz PINs: AuELA: -Model 1: RKModel 2: 1.0. DATA LI ...
MSRP $8.25
$6.22
MSRP $8.25
$6.22
26
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Interior lamps. 2-pin. Belt locking retractor. 2-pin. Dome lamp,front. 2-pin. Unipolar. 2-pin. Economy drive switch. 4-pole. 2-pin. Trunk lid. 2-pin. Stop light switch 2 polig. 2-pin. Asd/asr. 2-pin. Thermo-switch heating washer system. 2-pin. Parking brake control. 2-pin.
29
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Folding top actuation valve. 2-pin. Valve strip. 2-pin. Belt locking unit,bipolar. 2-pin. Foglamp. 2-pin. Window regulator valve. 2-pin. Foglight. 2-pin.
MSRP $3.50
$2.67
MSRP $3.50
$2.67
38
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 2.5 M. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. TO 201 540 02 81. 0.35-2.5 MM2 RK2.5Leitungsquerschni ...
MSRP $2.70
$2.03
MSRP $2.70
$2.03
50
Electric Coupling Mercedes-Benz
Mercedes-Benz Description: Blinker lamp. 2-pin rk4. Circulation pump m13. 2-pin rk4. Circulation pump 2-pin. 2-pin rk4.
MSRP $3.00
$2.29
MSRP $3.00
$2.29
59
MSRP $3.70
$2.82
65
Cap Mercedes-Benz
Mercedes-Benz Description: Blower. 2-pin rk4. Back-up lamp cable. 2-pin rk4. To a 008 545 09 28. 2-pin rk4. To a 008 545 08 28. 2-pin rk4. Secondary air pump m33. 2-pin rk4. To 008 545 08 28/008 545 09 28. 2-pin rk4. Air injection m33. 2-pin rk4.
68
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Engine cable harness plug-connection. 3-pin. Tail lamp cable harness plugconnection 3 polig. 3-pin. Heating water valve. 3-pin. Duo-water valve. 3-pin.
71
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 4,0 MM. 0.35-6.0 MM2 RK4.0
Leitungsquerschnitt Min/Max: 0,35-6,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: RK
Model 2: 4.0
Release tool: W220 589 01 99 52. TO 008 545 08 28,000 821 22 26. 0.35-6.0 MM2 RK4.0
Leitungsquerschnitt Min/Max: 0,35-6,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: RK
Model 2: 4.0
Release tool: W220 589 01 99 52.
Leitungsquerschnitt Min/Max: 0,35-6,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: RK
Model 2: 4.0
Release tool: W220 589 01 99 52. TO 008 545 08 28,000 821 22 26. 0.35-6.0 MM2 RK4.0
Leitungsquerschnitt Min/Max: 0,35-6,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: RK
Model 2: 4.0
Release tool: W220 589 01 99 52.
MSRP $3.40
$2.54
MSRP $3.40
$2.54
83
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Cable-harness plug-connection, 8-pole. Steering column adjustment cable plugconnection. Inboard cable harness plug-connection asr. Engine cable harness plug-connection to frame mounted cable harness. Headlamp cable harness. Plug connection, separation point. Module box.
84
Contact Pin Mercedes-Benz
Mercedes-Benz Description: To 016 545 01 28. 0.35-2.5 mm2 rk2.5. To 020 545 49 28. 0.35-2.5 mm2 rk2.5. 0,5-1,0mm2, to 023 545 52 28. 0.35-2.5 mm2 rk2.5. Only used with acceleration skid control (asr). 0.35-2.5 mm2 rk2.5. (lock angle sensor) 4.0 mm. 0.35-2.5 mm2 rk2.5. 2,5mm. 0.35-2.5 mm2 rk2.5. 0.25-2.5 mm. 0.35-2.5 mm2 rk2.5.
MSRP $7.75
$5.84
MSRP $7.75
$5.84
85
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Light switch module. 21-pin. Exterior lamp switch (module). 21-pin.
86
Cap Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: To a 017 545 42 28. To 017 545 72 28. To 210 545 55 28. To a 210 545 56 28.
87
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
MSRP $3.50
$2.67
MSRP $3.50
$2.67
87
Spring Retaining Pin Mercedes-Benz
Mercedes-Benz Description: 1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
MSRP $3.90
$2.92
MSRP $3.90
$2.92
89
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 0.5-1.5mm2. 0.5-0.75 MM2 MQS ELA
Leitungsquerschnitt Min/Max: 0,5-0,75mm2
Oberflächenschutz PINs: Au
ELA: +
Model 1: MQS
Release tool: W220 589 01 99 60.
Leitungsquerschnitt Min/Max: 0,5-0,75mm2
Oberflächenschutz PINs: Au
ELA: +
Model 1: MQS
Release tool: W220 589 01 99 60.
MSRP $5.25
$3.94
MSRP $5.25
$3.94
91
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Accelerator pedal switch. 4-pin. Warning buzzer. 4-pin. Oxygen sensor plug connection. 4-pin. Push to talk. 4-pin.
92
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Tempomat switch. 6-pin rk2.5. Change-over valve. 6-pin rk2.5. Belt feeder electronics,six-pole. 6-pin rk2.5. Push-button switch,cruise control. 6-pin rk2.5. Overheat warning indicator plugconnection. 6-pin rk2.5. Tempomat (cruise control). 6-pin rk2.5.
95
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Dome lighting. 8-pin. Steering column jacket tube adjustment switch. 8-pin. Separation point ads. 8-pin. Dome lamp,front. 8-pin. Plug connection. 8-pin. Steering column electrically adjustable 8-polig. 8-pin. Steering column adjustment motor 8-polig. 8-pin. Tempomat switch. 8-pin.
98
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 4 MM. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. 2,5 (AX). 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Ma ...
MSRP $2.90
$2.16
MSRP $2.90
$2.16
110
Contact Spring Mercedes-Benz
Mercedes-Benz Description: 0,5-1,0 MM2. 0.5-1.0 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: +
Model 1: JPT
Model 2: 2.8.
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: +
Model 1: JPT
Model 2: 2.8.
110
Contact Spring Mercedes-Benz
Mercedes-Benz Description: 1.5-2.5 MM2, TO 001 540 91 81. 1.5-2.5 MM2 JPT
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Ag
ELA: +
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 82. VACUUM SENSOR A7/7. 1.5-2.5 MM2 JPT
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Ag
ELA: +
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 82.
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Ag
ELA: +
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 82. VACUUM SENSOR A7/7. 1.5-2.5 MM2 JPT
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Ag
ELA: +
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 82.
MSRP $3.90
$2.92
MSRP $3.90
$2.92
113
Receptacle Housing Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Wiper motor. 5-pin. Pane wiper. 5-pin.
116
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, driver k40/2. L3. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: SPTRelease tool: W000 589 13 99 30. Copper. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PI ...
MSRP $3.90
$2.92
MSRP $3.90
$2.92
116
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Description: Repair solution contacting 0.75mm2. 0.75 mm2 e95. Fuse box. 0.75 mm2 e95.
MSRP $6.50
$4.83
MSRP $6.50
$4.83
116
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, driver k40/2. Fuse and relay module, front passenger k40/4. FUSE AND RELAY BOX,DRIVER. 1.0-2.5 MM2 SPT
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
MSRP $4.90
$3.68
MSRP $4.90
$3.68
119
Plug Mercedes-Benz
Mercedes-Benz Description: Control for electric suction-type fan. 7-pin jpt, lsk8.
MSRP $11.00
$8.26
MSRP $11.00
$8.26
122
Electric Line Mercedes-Benz
Mercedes-Benz Description: FAN MOTOR M4/3. 6.0 MM2 LSK8 AGLeitungsquerschnitt Min/Max: 6,0mm2Oberflächenschutz PINs: AgModel 1: LSKModel 2: 8Release tool: W220 589 01 99 56. FLAT PLUG 4.0 - 6.0 MM2. 6.0 MM2 LSK8 AGLeitungsquerschnitt Min/Max: 6,0mm2Oberflächenschutz PINs: AgModel ...
MSRP $18.50
$13.97
MSRP $18.50
$13.97
122
125
Gasket Mercedes-Benz
Mercedes-Benz Description: BLIND PLUG, YELLOW 11.8mm MLK1.2/LSK8. 11.8 MM MLK1.2/LSK8Leitungsquerschnitt Min/Max: 11,8mm2ELA: +Model 1: MLK1.2 / LSK8Model 2: 1.2 / 8Release tool: W220 589 01 99 25 / W220 589 01 99 56. To 012 545 12 26. TO 009 545 27 26. 11.8 MM MLK1.2/LSK8Leitungsqu ...
MSRP $2.40
$1.78
MSRP $2.40
$1.78
125
Gasket Mercedes-Benz
Mercedes-Benz Description: BLACK 4.5-6.2 MM. 4.5-6.2 MM2 LSK8
Leitungsquerschnitt Min/Max: 4,5mm2-6,2mm2
ELA: +
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56. 6.0 MM2. 4.5-6.2 MM2 LSK8
Leitungsquerschnitt Min/Max: 4,5mm2-6,2mm2
ELA: +
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56.
Leitungsquerschnitt Min/Max: 4,5mm2-6,2mm2
ELA: +
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56. 6.0 MM2. 4.5-6.2 MM2 LSK8
Leitungsquerschnitt Min/Max: 4,5mm2-6,2mm2
ELA: +
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56.
MSRP $4.70
$3.56
MSRP $4.70
$3.56
125
Blanking Plug Mercedes-Benz
Mercedes-Benz Description: SPT
Leitungsquerschnitt Min/Max: 7,2-7,3mm2
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30. Blind plug, black a13. Blind plug, white spt. To 029 545 75 28. Blind plug to 034 545 93 28.
Leitungsquerschnitt Min/Max: 7,2-7,3mm2
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30. Blind plug, black a13. Blind plug, white spt. To 029 545 75 28. Blind plug to 034 545 93 28.
MSRP $5.50
$4.19
MSRP $5.50
$4.19
134
MSRP $4.50
$3.43
155
Socket Mercedes-Benz
Mercedes-Benz Description: Additional blinker lamp. Position lamp. Turn signal lamp E6/3,E6/4. Left blinker light. License plate lamp. Side marker lamps e6/3-e6/4.
MSRP $20.00
$14.90
MSRP $20.00
$14.90
179
Wiper Arm Nut Mercedes-Benz
Mercedes-Benz Description: Master cylinder to brake booster. Rear bumper to rear body panel cross member. Electric cable to alternator. Pedal assembly to fire wall. Front bumper to cross member. Armrest to backrest. Bracket to bumper. Left stiffening to right stiffening. On front door,bottom.
MSRP $3.40
$2.53
MSRP $3.40
$2.53
182
Spring Washer Mercedes-Benz
Mercedes-Benz Description: Wiper arm with blade to wiper spindle. Drive rod to crank arm. Wiper arm to wiper shaft. Wiper arm on spindle.
MSRP $1.50
$1.14
MSRP $1.50
$1.14
185
Cap Mercedes-Benz
Mercedes-Benz Description: Cable to starting motor,terminal 30. Mount, battery line to terminal on alternator. Cable to alternator klemme 30. Alternator-to-starting-motor cable. Alternator,terminal b+. Cable to alternator,terminal 30.
MSRP $2.40
$1.78
MSRP $2.40
$1.78
215
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: M6. Bracket to water tank. Mounting parts. Control unit. Bracket mounting. Brake booster assembly to asr bracket. Fuel lines to cowl. Transistorized ignition switchgear to wheelhouse panel. Roller blind to rear panel covering, top.
MSRP $3.40
$2.54
MSRP $3.40
$2.54
221
MSRP $2.50
$1.91
